Plot Plan (unknown)
Archive
This architectural drawing features the plot plan for a studio/residence found in California. It includes measurements. A circle in the bottom right reads 'Plan 5/Sheet 5.'
2008.12.19j
Carl HoermanArchitectural drawings, plans and renderings
Christine Nienhuis
Architectural DrawingsBlueprintsCarl Hoermanowner unknownCalifornia
Flat Files drawer 03 Hoerman plans (1 of 2)
Good
Hoerman, Carl 1885-1955
Hoerman, Siegfried
Notes: California Status: OK Status By: Christine Nienhuis Status Date: 2014-03-18
03/18/2014
04/18/2023
